INTEL Server System R1208SPOSHORR 1u rack system with S1200SPOR board and 8 x 2.5 hot-swapable HDD Drive cage
Dane główne
nie stanowią oferty handlowej w rozumieniu przepisów kodeksu cywilnego.
Regulamin
Opis
Code Name
Silver Pass
Essentials
Limited 3-year Warranty
Yes
Extended Warranty Available for Purchase (Select Countries)
Yes
Additional Extended Warranty Details
Single Processor System Extended Warranty
Compatible Product Series
Intel® Xeon® Processor E3-1200 v5 Family
Chassis Form Factor
1U Rack
Chassis Dimensions
17.26"x23.84"x1.7" (WxDxH)
Board Form Factor
uATX
Rack Rails Included
No
Socket
1
System Board
Intel® Server Board S1200SP Family
Board Chipset
Intel® C236 Chipset
Target Market
Entry
Rack-Friendly Board
Yes
Power Supply
450 W
Power Supply Type
AC
# of Power Supply Included
2
Redundant Fans
No
Redundant Power Supported
Yes
Heat Sink
F1UE3PASSHS
Heat Sink Included
Yes
Backplanes
Included
Included Items
(1) Intel® Server Board S1200SPOR, (1) Riser card assembly (AXX1UPCIEX16R2), (2) 450W redundant power supply, (1) Power Distribution Board, (8) 2.5 inch Hot-swap drive bays with (8) 2.5 inch Hot-swap drive trays (FXX25HSCAR2), and (1) 12Gb SAS Backplane (F1U8X25S3HSBP), (1) SATA data cable, (1) Backplane 12C cable, (1) SATA ODD data cable, (1) SAS Data cable, (3) System fans, (1) Standard control panel assembly, (1) Front I/O Panel assembly (1 x VGA & 2 x USB), (1) SATA Optical drive bay with filler panel, (2) Chassis handles -installed
# of Front Drives Supported
8
Front Drive Form Factor
Hot-swap 2.5"
# of Internal Drives Supported
1
Internal Drive Form Factor
M.2 SSD
Supplemental Information
Description
Intel® Server System R1208SPOSHORR, 1u rack system with S1200SPOR board and 8 x 2.5 hot-swapable HDD Drive cage, 2 x 450W redundant power supplies
Memory & Storage
Memory Types
DDR4 ECC UDIMM
Max # of DIMMs
4
Max Memory Size (dependent on memory type)
64 GB
DIMM Type
UDIMM
Graphics Specifications
Integrated Graphics ‡
No
Expansion Options
Connector for Intel® I/O Expansion Module x8 Gen 3
1
Connector for Intel® Integrated RAID Module
1
Riser Slot 1: Total # of Lanes
8
Riser Slot 1: Included Slot Configuration(s)
1x PCIe Gen3 x8
I/O Specifications
# of USB Ports
9
Total # of SATA Ports
8
RAID Configuration
Software RAID RSTe (0,1,10,5) and ESRT2 (0,1,10)
# of Serial Ports
1
Integrated LAN
i210
# of LAN Ports
2
Optical Drive Support
Yes
Package Specifications
Max CPU Configuration
1
Advanced Technologies
Intel® Remote Management Module Support
Yes
Integrated BMC with IPMI
IPMI 2.0
Intel® Node Manager
Yes
Intel® Rapid Storage Technology enterprise
Yes
Intel® I/O Acceleration Technology
Yes
Intel® Transparent Supply Chain
TPM Version
1.2
Intel R1208SPOSHORR. Układ płyty głównej: Intel® C236, Typ procesora: Intel, Procesor: Intel® Xeon®. Obsługiwane rodzaje pamięci: DDR4-SDRAM, Maksymalna pojemność pamięci: 64 GB. Nadmiarowe kontrolery: RSTe, Kontrolujący (drugi) rodzaj interfejsu: ESRT2, Poziomy raid: 0, 1, 5, 10. Kontrloer LAN: Intel i210. Rozmiar układu: uATX, Obudowa: 1U Rack, Radiator: F1UE3PASSHS
Parametry techniczne
Parametry techniczne produktu
- Układ płyty głównej
- Intel® C236
- Liczba obsługiwanych procesorów
- 1
- Typ procesora
- Intel
- Procesor
- Intel® Xeon®
- Intel® Xeon series
- E3-1200
- Ilość slotów DIMM
- 4
- Obsługiwane rodzaje pamięci
- DDR4-SDRAM
- Kod korekcyjny
- Tak
- Maksymalna pojemność pamięci
- 64 GB
- Przemieszczanie twardej wnęki na napęd
- Tak
- Ilość obsługiwanych rozmiarów dysków pamięci
- 8
- Nadmiarowe kontrolery
- RSTe
- Kontrolujący (drugi) rodzaj interfejsu
- ESRT2
- Poziomy raid
- 0, 1, 5, 10
- Obsługiwane rozmiary dysków pamięci
- 2.5"
- Kontrloer LAN
- Intel i210
- Przewodowa sieć lan
- Tak
- Ilość portów Ethernet LAN (RJ-45)
- 2
- Szeregowe porty komunikacyjne
- 1
- Model karty graficznej on-board
- Niedostępny
- Rozmiar układu
- uATX
- Obudowa
- 1U Rack
- Relingi
- Nie
- Radiator dołączony
- Tak
- Radiator
- F1UE3PASSHS
- Płyta Rack-Friendly
- Tak
- Trusted Platform Module (TPM)
- Tak
- Wersja TPM
- 1.2
- Intel® Remote Management Module Support
- Yes
- Zintegrowany BMC z IPMI
- Tak
- Obsługa Backplanes
- Tak
- Intel® Intel®ligent Power Node Manager
- Tak
- Wewnętrzny moduł I / O Expansion x8 Gen 3
- 1
- Technologia Intel® Rapid Storage Technology enterprise
- Tak
- Technologia Intel® WE/WY Acceleration
- Tak
- Zasilanie
- 450 W
- Liczba nadmiarowych dostaw zasilania
- 2
- Zasilacz nadmiarowy
- Tak
- Typ zasilacza
- AC
- Ilość jednostek zasilania
- 2
- ARK ID
- 97954
- Intel® Server Management Software
- Tak
- Ilość zatok 2,5 "
- 8
- Zawartość opakowania
- (1) Intel Server Board S1200SPOR, (1) Riser card assembly (AXX1UPCIEX16R2), (2) 450W redundant power supply, (1) Power Distribution Board, (8) 2.5 inch Hot-swap drive bays with (8) 2.5 inch Hot-swap drive trays (FXX25HSCAR2), and (1) 12Gb SAS Backplane (F1U8X25S3HSBP), (1) SATA data cable, (1) Backplane 12C cable, (1) SATA ODD data cable, (1) SAS Data cable, (3) System fans, (1) Standard control panel assembly, (1) Front I/O Panel assembly (1 x VGA & 2 x USB), (1) SATA Optical drive bay with filler panel, (2) Chassis handles -installed
- Typ produktu
- 15
- Łączna liczba złączy SATA
- 8
- Ilość portów USB
- 9
- Maksymalna pamięć wewnętrzna wspierana przez procesor
- 64 GB
- Szerokość produktu
- 438,4 mm
- Długość urządzenia
- 605,5 mm
- Wysokość urządzenia
- 43,2 mm
- Maksymalna konfiguracja CPU
- 1
- Karta graficzna on-board
- Nie
- Rodzina produktów
- System serwera 1U
- Status
- Launched
