fractal design Chłodzenie wodne Celsius S24 Blackout

The Celsius series builds upon proven technology with cutting edge advancements and premium sound dampening materials to deliver extreme cooling performance with minimum noise output. Smart dual mode speed controls are both simple and robust with no need for additional software. Both fan and pump speeds can be managed by an intelligent auto mode or switched to PWM mode for precise user control. For true enthusiasts, the satisfaction of a clean and efficient build can never be overstated, and the Celsius makes this easier than ever with an integrated fan hub and concealed cable routing. Key features: The Celsius series uses a combination of cutting edge technology and premium sound dampening materials to deliver extreme cooling performance with minimum noise output. An intelligent temperature-controlled auto mode adjusts fan and pump speeds in real-time for optimum balance of cooling performance and silence, while PWM mode enables precision manual tuning for any usage situation. Included Fractal Design Dynamic X2 PWM fans offer a wide speed adjustment range from 500 to 2000 RPM allowing for near silent operation under lighter loads and maximum airflow during heavy usage. An integrated fan hub with concealed cable routing simplifies cable management for a clean installation. Radiator fittings use standard G 1/4" thread for maximum compatibility and expandability with standard do-it-yourself components. Easily add and integrate a GPU block of your choice to eliminate noisy graphics card fans so the only sound you hear is the sound of your game. General Specification Coldplate technology Fifth generation Coldplate material Copper Additional sound dampening Integrated Thermal paste Pre-applied, high thermal conductivity Sockets supported (Intel) 1150, 1151, 1155, 1156, 1366, 2011, 2011-v3 Sockets supported (AMD) AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+ Tube length 400 mm Tube material Sleeved low-permability rubber tubes Fittings, block side Durable metal fittings, non-removable Fittings, radiator side Durable metal fittings, G 1/4" thread Thermal paste Pre-applied, high thermal conductivity Fan control Integrated dual mode Warranty 5-year (Upon Expansion of the Celsius unit, only individual components of the Fractal Design Celisus S24 or S36 are covered) Fan specification Fan type Fractal Design Dynamic X2 GP-12 PWM Rotational speed 500-2000 RPM Bearing LLS bearing PWM control Yes Acoustical noise (full speed) 32.2 dB(A) Maximum air flow 148.8 m3/h | 87.6 CFM Maximum static pressure 2.30 mm H2O Input voltage 12 V DC Maximum input current 0.2A MTBF >100,000 Pump specification Rotational speed 1950-3150 RPM Bearing type Ceramic bearing and shaft PWM control Yes Acoustical noise (full speed) 20,0 dB(A) Maximum pressure, 50°C 1m H2O | 1.45 PSI Input voltage 12 V DC Input current (without fans) 0.15 A Rated input power (with fans) 6.6W MTTF >50,000 hours Radiator specification Dimensions 284*122*31 mm Housing material Aluminium Fin material Aluminium Port threads G 1/4" Fan screw threads UNC 6-32 Package contents Celsius S24 system 2 pcs Dynamic X2 GP-12 PWM fans Multilingual user manual Mounting hardware for all listed sockets Fan and radiator mounting screws

Typ produktu: Chłodzenie wodne
Czarny kolor
EAN: 7340172701859
Kod producenta: FD-WCU-CELSIUS-S24-BKO
Typ produktu: zestaw do chłodzenia wodą
Pasujące gniazda: 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+, AM4, 2066, TR4, sTRX4, 1200
Mocowanie: skręcane
Głośność: 32,2dB
Wyposażenie: pasta termiczna/podkładka
Prędkość: 500 do 2000 obr/min
Materiał radiatora: aluminium, miedź
Przepływ: 148,8 m3/h (87,6 cfm)
Ciśnienie powietrza: do 2,3 mm/H2O
Rozmiar grzejnika: 2x 120 mm
System: system zamknięty
Złącze zasilania: 4-pinowe PWM
Zakres napięcia: 12 woltów
Informacje dodatkowe: Wymiary węży: 400 mm (1/4"), węże gumowe zakryte i nieprzepuszczalne, sterowanie wentylatorem: zintegrowany tryb podwójny
Uwaga: obsługiwane gniazda: TR4 przy użyciu wspornika w pudełku AMD Threadripper, 2066 przy użyciu dołączonego zestawu 2011-v3
Akcesoria: materiały montażowe, instrukcje
Wymiary: Ilość: 2 sztuki, szerokość: 120 mm, wysokość: 120 mm, głębokość: 25 mm
: Szerokość: 284mm x Wysokość: 122mm x Głębokość: 31mm
: Szerokość: 284mm x Wysokość: 122mm x Głębokość: 56mm
Waga: 1,8 kg
