hewlett packard enterprise HPE Aruba IOn 1960 12XT 4XF Switch Europe - English

Aruba Instant On 1960 12XGT 4SFP+ Switch (JL805A) SpecificationsI/O ports and slots12 RJ-45 autosensing 100/1000/10GBASE-T ports(IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.an 10GBASE-T); Duplex: 100BASE-TX: half or full; 1000BASE-T: full only 10GBASE-T: full only4 SFP+ 10GbE ports Dimensions 350.5(d) x 442.5(w) x 43.95(h) mmWeight 9.6 lb (4.3 kg) CPU Single Core ARMv7 Cortex-A9 @2Ghz100 Mb Latency < 7.4 uSec1000 Mb Latency < 4.2 uSec10000 Mb Latency < 1.1 uSecThroughput (Mpps) 238 Mpps Capacity 320 Gbps Routing Table size (# of static entries) 512 IPv4/IPv6MAC Address table size (# of entries) 16,000 entriesReliability MTBF (years) 88.8Operating temperature 0-40°C, 0-10,000 ftOperating relative humidity 15% to 95% @ 104°F (40°C) non-condensingNonoperating/Storage temperature -40°F to 158°F (-40°C to 70°C) up to 15000 ftNonoperating/Storage relative humidity 15% to 90% @ 149°F (65°C) non-condensingAltitude up to 10,000 ft (3 km) Idle 4.1 100% Traffic 4.1 100% Traffic / 0% PoE -100% Traffic / 50% PoE -100% Traffic / 100% PoE - Electrical CharacteristicsFrequency 50Hz/60HzAC voltage 100-127VAC / 200-240VACCurrent 1.3A/0.4A Maximum power rating 100-127V: 130W 200-220V: 160WIdle power 100-127V: 60W 200-220V: 80WPoE power -Power Supply Internal power supply Safety EN/IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013EN/IEC 62368-1, 2nd. & 3rd. Ed.UL 62368-1, 2nd. & 3rd. Ed.CAN/CSA C22.2 No. 62368-1, 2nd. & 3rd. Ed.EN/IEC 60825-1:2014 Class 1 Emissions EN 55032:2015/CISPR 32, Class AFCC CFR 47 Part 15: 2018 Class AICES-003 Class AVCCI Class ACNS 13438 Class AKN 32 Class AAS/NZS CISPR 32 Class A Generic EN 55035, CISPR 35, KN35 EN EN 55035, CISPR 35 ESD EN/IEC 61000-4-2 Radiated EN/IEC 61000-4-3 EFT/Burst EN/IEC 61000-4-4 Surge EN/IEC 61000-4-5 Conducted EN/IEC 61000-4-6 Power frequency magnetic field EN/IEC 61000-4-8 Voltage dips and interruptions EN/IEC 61000-4-11 Harmonics EN/IEC 61000-3-2 Flicker EN /IEC 61000-3-3 Device Management: Aruba Instant On Cloud; Web browser; SNMP Manager Mounting Positions and Supported Racking Mounts in an EIA-standard 19 in. telco rack or equipment cabinet. 2-post rack kit includedSupports table-top mountingSupports rack-mountingSupports wall-mounting with ports facing either up or downSupports under-table mounting using the brackets providedTransceivers Aruba 1G SFP LC SX 500m MMF Transceiver (J4858D)Aruba 1G SFP LC LX 10km SMF Transceiver (J4859D)Aruba 1G SFP RJ45 T 100m Cat5e Transceiver (J8177D)Aruba 10G SFP+ LC SR 300m MMF Transceiver (J9150D)Aruba 10G SFP+ LC LR 10km SMF Transceiver (J9151E)Aruba 10G SFP+ to SFP+ 1m DAC (J9281D)Aruba 10G SFP+ to SFP+ 3m DAC (J9283D)
