asrock Płyta główna B760M STEEL LEGEND WIFI s1700 4DDR5 DP/HDMI mATX
Dane główne
nie stanowią oferty handlowej w rozumieniu przepisów kodeksu cywilnego.
Regulamin
Opis
B760M Steel Legend WiFi Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700) 12+1+1 Power Phase, Dr.MOS for VCore+GT Supports DDR5 7200MHz (OC) 1 PCIe 5.0 x16, 1 PCIe 4.0 x1 Graphics Output Options: HDMI, DisplayPort, eDP Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio 4 SATA3, 3 Hyper M.2 (PCIe Gen4x4) 2 USB 3.2 Gen2 Type-C (1 Rear, 1 Front), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (4 Rear, 2 Front), 6 USB 2.0 (2 Rear, 4 Front) Dragon 2.5G LAN, 802.11ax (WiFi 6E) + Bluetooth 5.3 Supports ASRock Auto Driver Installer Unique Feature Superb Productivity- PCIe Gen5 (Graphics)- Dual Channel DDR5Rock-Solid Durability- 12+1+1 Power Phase, 50A Dr.MOS for VCore+GT- Flexible Integrated I/O Shield- Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) for VCoreUltrafast Connectivity- 2.5G LAN, 802.11ax Wi-Fi 6E ModuleEZ Update- ASRock Auto Driver InstallerEZ Troubleshooter- ASRock Post Status Checker CPU - Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700)- Supports Intel® Hybrid Technology- Supports Intel® Turbo Boost Max 3.0 Technology- Supports Intel® Thermal Velocity Boost (TVB)- Supports Intel® Adaptive Boost Technology (ABT) Chipset - Intel® B760 Memory - Dual Channel DDR5 Memory Technology- 4 x DDR5 DIMM Slots- Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*- Max. capacity of system memory: 128GB- Supports Intel® Extreme Memory Profile (XMP) 3.0 *1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively.1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively.2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively.2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively. BIOS - 128Mb AMI UEFI Legal BIOS with GUI support Graphics - Intel® Xe Graphics Architecture (Gen 12)- 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz- 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz *Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)- Nahimic Audio LAN - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s- Dragon RTL8125BG- Supports Dragon 2.5G LAN Software- Smart Auto Adjust Bandwidth Control- Visual User Friendly UI- Visual Network Usage Statistics- Optimized Default Setting for Game, Browser, and Streaming Modes- User Customized Priority Control Wireless LAN - 802.11ax Wi-Fi 6E Module- Supports IEEE 802.11a/b/g/n/ac/ax- Supports Dual-Band 2x2 with extended 6GHz band support*- 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology- Supports Bluetooth 5.3 + High speed class II- Supports MU-MIMO *Wi-Fi 6E (6GHz band) will be supported by Microsoft® Windows® 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.A 6GHz compatible router is required for 6E functionality. Slots CPU:- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*Chipset:- 1 x PCIe 4.0 x1 Slot (PCIE2)*- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT)- 15µ Gold Contact in VGA PCIe Slot (PCIE1) *Supports NVMe SSD as boot disks Storage CPU:- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*Chipset:- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*- 4 x SATA3 6.0 Gb/s Connectors *Supports Intel® Volume Management Device (VMD)Supports NVMe SSD as boot disks RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices USB - 2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front)- 1 x USB 3.2 Gen2 Type-A (Rear)- 6 x USB 3.2 Gen1 (4 Rear, 2 Front)- 6 x USB 2.0 (2 Rear, 4 Front)* All USB ports support ESD Protection Connector - 1 x eDP Signal Connector- 1 x SPI TPM Header- 1 x Chassis Intrusion and Speaker Header- 1 x RGB LED Header*- 3 x Addressable LED Headers**- 1 x CPU Fan Connector (4-pin)***- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****- 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)- 1 x Front Panel Audio Connector- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)- 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) *Supports in total up to 12V/3A, 36W LED Strip **Support in total up to 5V/3A, 15W LED Strip ***CPU_FAN1 supports the fan power up to 1A (12W). ****CPU_FAN2/WP supports the fan power up to 2A (24W). *****CHA_FAN1~3/WP support the fan power up to 2A (24W).CPU_FAN2/WP and CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Ports- 1 x PS/2 Mouse/Keyboard Port- 1 x HDMI Port- 1 x DisplayPort 1.4- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)- 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)- 4 x USB 3.2 Gen1 Ports- 2 x USB 2.0 Ports- 1 x RJ-45 LAN Port- HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software- ASRock Motherboard Utility (A-Tuning)- ASRock Dragon 2.5G LAN Software- ASRock Polychrome SYNC*UEFI- ASRock EZ Mode- ASRock Full HD UEFI- ASRock My Favorites in UEFI- ASRock Auto Driver Installer- ASRock Instant Flash- ASRock Easy RAID Installer *These utilities can be downloaded from ASRock Live Update & APP Shop. Accessories - 1 x User Manual- 2 x SATA Data Cables- 2 x ASRock WiFi 2.4/5/6 GHz Antennas- 3 x Screws for M.2 Sockets- 3 x Standoffs for M.2 Sockets Form Factor - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm- 2oz Copper PCB OS - Microsoft® Windows® 10 64-bit / 11 64-bit Certifications - FCC, CE- ErP/EuP ready (ErP/EuP ready power supply is required)
Parametry techniczne
Parametry techniczne produktu
- Opis
-
B760M STEEL LEGEND WIFI
- Obsługuje procesory Intel Core 13-ej i 12-ej generacji (LGA1700)
- 12+1+1 Power Phase, Dr.MOS for VCore+GT
- Obsługuje DDR5 7200MHz (OC)
- 1 PCIe 5.0 x16, 1 PCIe 4.0 x1
- Wyjścia grafiki: HDMI, DisplayPort, eDP
- Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
- 4 SATA3, 3 Hyper M.2 (PCIe Gen4x4)
- 2 USB 3.2 Gen2 Type-C (1 Tył, 1 Przód),
- 1 USB 3.2 Gen2 Type-A (Tył),
- 6 USB 3.2 Gen1 (4 Tył, 2 Przód),
- 6 USB 2.0 (2 Tył, 4 Przód)
- Dragon 2.5G LAN, 802.11ax (WiFi 6E) + Bluetooth 5.3
- Obsługuje ASRock Auto Driver Installer
- Model
-
B760M STEEL LEGEND WIFI
- Gniazdo procesora
- LGA1700
- Rodzina procesora
-
- Intel Celeron,
- Intel Core i9,
- Intel Core i7,
- Intel Pentium,
- Intel Core i3,
- Intel Core i5
- Zintegrowany procesor
- Nie
- Producent chipsetu MB
- Intel
- Chipset
-
Intel B760
- Rodzaj pamięci
- DDR5
- Liczba gniazd DDR5
- 4
- Częstotliwość szyny pamięci
- 7200 MHz
- Maks. wielkość pamięci
- 128 GB
- Gniazda rozszerzeń
-
- 1 x PCIe 5.0 x16,
- 1 x PCIe 4.0 x 1
- Maksymalna ilość urządzeń SATA
- 4
- RAID
- Tak
- Szczegółowe dane o interfejsach dysków/napędów
-
CPU:
- 1 x Hyper M.2 Socket (M2_1, Key M), obsługuje 2260/2280 PCIe Gen4x4 (64 Gb/s)
Chipset:
- 1 x Hyper M.2 Socket (M2_2, Key M), obsługuje type 2260/2280 PCIe Gen4x4 (64 Gb/s)
- 1 x Hyper M.2 Socket (M2_3, Key M), obsługuje type 2260/2280 PCIe Gen4x4 (64 Gb/s)
- 4 x złącze SATA3 6.0 Gb/s
- Grafika
-
- Architektura graficzna Intel Xe (12. generacji)
- eDP 1.4, obsługuje maks. rozdzielczość do Full HD 60 Hz
- HDMI 2.1 kompatybilny z TMDS, obsługuje HDCP 2.3 i max. rozdzielczość do 4K 60 Hz
- DisplayPort 1.4 z DSC (skompresowany), obsługuje HDCP 2.3 i maks. rozdzielczość do 8K 60Hz / 5K 120Hz
*Wbudowane grafiki Intel UHD i wyjścia VGA mogą być obsługiwane tylko przez procesory ze zintegrowanym GPU.
- Karta dźwiękowa
-
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
- Nahimic Audio
- Interfejs sieciowy
-
LAN:
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
- Dragon RTL8125BG
- Supports Dragon 2.5G LAN Software
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and Streaming Modes
- User Customized Priority Control
Wireless LAN:
- 802.11ax Wi-Fi 6E Module
- Supports IEEE 802.11a/b/g/n/ac/ax
- Supports Dual-Band 2x2 with extended 6GHz band support
- 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
- Supports Bluetooth 5.3 + High speed class II
- Supports MU-MIMO
- Porty USB na tylnym panelu
- 8
- Porty USB do wyprowadzenia z płyty
- 7
- Liczba portów USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1
- 6
- Liczba portów USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2
- 3
- FireWire (IEEE 1394)
- Nie
- Port / Złącze COM (szeregowy)
- Nie
- Port / Złącze LPT (równoległy)
- Nie
- Złącza zewnętrzne
-
- 1 x Line Out (zielony / headphones),
- 1 x MIC (różowy / microphone),
- 1 x RJ-45,
- 2 x USB 2.0,
- 4 x USB 3.0,
- 1 x USB 3.1,
- 1 x USB 3.1 Type-C,
- 1 x HDMI,
- 1 x Line In (błękitny),
- 1 x PS/2 Klawiatura/Mysz Combo,
- 1 x DisplayPort,
- 2 x SMA
- Złącza dostępne na płycie
-
- 1 x Przedni panel audio,
- 3 x 4pin wentylator obudowy chłodzenie cieczą,
- 2 x 8pin 12V zasilanie,
- 1 x 24pin ATX zasilanie,
- 3 x M.2,
- 4 x SATA III 6Gb/s,
- 4 x USB 2.0/1.1,
- 2 x USB 3.0,
- 1 x USB C,
- 1 x TPM,
- 1 x 4pin wentylator procesora chłodzenie cieczą,
- 1 x 4pin wentylator procesora,
- 1 x Czujnik otwarcia obudowy (chassis intrusion),
- 1 x Taśma LED RGB,
- 3 x Adresowalna dioda LED,
- 1 x eDP
- Funkcje specjalne
-
Superb Productivity:
- PCIe Gen5 (Graphics)
- Dual Channel DDR5
Rock-Solid Durability:
- 12+1+1 Power Phase, 50A Dr.MOS for VCore+GT
- Flexible Integrated I/O Shield
- Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) for VCore
Ultrafast Connectivity:
- 2.5G LAN, 802.11ax Wi-Fi 6E Module
EZ Update:
- ASRock Auto Driver Installer
EZ Troubleshooter:
- ASRock Post Status Checker
- Bios
-
128Mb AMI UEFI Legal BIOS z obsługą GUI
- Format płyty
- micro ATX
- Wymiary
-
24.4 x 24.4 cm
- Akcesoria w zestawie
-
- Instrukcja obsługi
- 2 x Kabel danych SATA
- 2 x Antena ASRock Wi-Fi 2,4/5/6 GHz
- 3 x Śruby do gniazda M.2
- 3 x Wsporniki do gniazda M.2
- Obsługiwane systemy operacyjne
-
- Windows 10,
- Windows 11
- Oprogramowanie
-
Software:
- ASRock Motherboard Utility (A-Tuning)
- ASRock Dragon 2.5G LAN Software
- ASRock Polychrome SYNC
UEFI:
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
- ASRock Easy RAID Installer
