Wentylator ARCTIC Alpine 23 AMD4/AMD3(+)/AMD2(+)/FM2/FM1

1207190-240426231401
ARCTIC COOLING
Opinie
29.98 zł
brutto za 1 szt
towar dostępny
Ilość:
<
od 10.99
około wt. 30.04 - czw. 02.05 u Ciebie
Oblicz ratę

Dane główne

1207190-240426231401
ARCTIC COOLING
ACALP00035A
4895213702829
od 10.99
2024-04-27
Dowiedz się więcej
Treści zawarte na stronie internetowej mają charakter informacyjny i
nie stanowią oferty handlowej w rozumieniu przepisów kodeksu cywilnego.

Opis

Alpine 23 Compact AMD CPU-Cooler IMPROVED COOLING PERFORMANCE BY NEW PRODUCTION PROCESS - The high thermal conductivity of aluminum is fully retained by a new type of extrusion. This new production process creates a powerful yet very compact radial heat sink. The particularly thin cooling fins of the new Alpine are fanned out in a Y-shape. This increases the surface area of the heat sink and therefore the cooling capacity. WIDE RPM RANGE - The Alpine 23 features a new motor technology with a very wide, PWM-controlled RPM range. This keeps the noise level at a minimum while guaranteeing maximum cooling performance when needed. LOWER POWER CONSUMPTION & MINIMUM VIBRATION - The new Alpine 23 is powered by an updated motor and runs much more efficiently than its predecessors. Due to sinus-magnetizing the new motor creates just 5 % of the vibration from commutation of a regular DC-motor. These factors contribute towards saving energy, lowering the coil temperature and reducing vibrations to a minimum without compromising performance. HIGH QUALITY BEARING - Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan. EXTENDED LIFE SPAN - A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. PRE-APPLIED MX-2 THERMAL PASTE - The pre-applied, high-performance MX-2 thermal compound ensures fast and clean installation. EASY AND TOOL-FREE INSTALLATION - Thanks to the mounting clips, the installation is really easy. Alpine 23 is simply plugged onto the existing AMD retention modules and screwed tight. TECHNICAL SPECIFICATIONS Compatibility AMD Socket AM4 Ram Clearance unlimited Warranty 6 years Operating Ambient Temperature 0 - 40°C Heatsink Outer Diameter 93.4 mm Fin Material Aluminum Number of Fins 50 Y-shaped Fins Thermal Paste MX-2 pre-applied Fan Fan Diameter 90 mm Fan Speed 100 - 2000 rpm Fan Bearing Fluid Dynamic Bearing Noise Level 0.3 Sone Current 0.06 A Connector 4-Pin Size & Weight Length 98.6 mm Width 121 mm Height 65 mm Weight 275.5

ARCTIC Alpine 23 - Compact AMD CPU-Cooler. Model: Chłodnica powietrza, Średnica czaszy wentylatora: 9 cm, Prędkość obrotowa (min): 100 RPM, Prędkość obrotowa (max): 2000 RPM, Poziom hałasu: 0,3 sony/sonów, Typ łożyska: Łożysko dynamiki płynów (FDB). Napięcie: 12 V. Szerokość produktu: 98,6 mm, Głębokość produktu: 121 mm, Wysokość produktu: 65 mm. Kolor produktu: Aluminium, Czarny

Parametry techniczne

Parametry techniczne produktu

Odpowiednia lokalizacja
Procesor
Model
Chłodnica powietrza
Średnica czaszy wentylatora
9 cm
Obsługiwane gniazda procesora
Socket AM4, Socket AM5
Prędkość obrotowa (min)
100 RPM
Prędkość obrotowa (max)
2000 RPM
Poziom hałasu
0,3 sony/sonów
Modulacja szerokości impulsu (PWM) wsparcie
Tak
Typ łożyska
Łożysko dynamiki płynów (FDB)
Ilość na paczkę
1 szt.
Kolor produktu
Aluminium, Czarny
Tworzywo chłodnicy
Aluminium
Liczba wentylatorów
1 went.
Złącze wentylatora
4-pin
Napięcie
12 V
Natężenie znamionowe
0,06 A
Szerokość produktu
98,6 mm
Głębokość produktu
121 mm
Wysokość produktu
65 mm
Waga produktu
275,5 g
Średnica ciepłowodów
3,2 cm
Szerokość opakowania
111 mm
Głębokość opakowania
111 mm
Wysokość opakowania
76 mm
Waga wraz z opakowaniem
275 g
Rodzaj opakowania
Pudełko
Zestaw do montażu
Tak
