OBUDOWA FRACTAL DESIGN NODE 804 WINDOW USB3.0 CZARNA

http://www.fractal-design.com/home/product/cases/node-series/node-804The Node 804 is a micro ATX chassis which focuses on cooling performance and maximum configurability, all packed in an interesting new form factor with Scandinavian elegant design.The dual chamber layout separates hot running components from the cooler ones and allows for unrestricted airflow over the motherboard, processor and graphics card.The case comes with three excellent 120mm fans but can be upgraded with several additional fans if needed.Featuring plenty of options for placing water cooling components, tall heat sinks and hard drives.The flexibility of this case really gives the users the possibility to create their optimal system build. Key featuresHighly effective dual chamber case layout for best possible cooling.Minimalistic design with an elegant brushed aluminum front panelUnique hard drive mounting system, fitting up to 8 x 3.5”, 4 x 2.5” or up to 10 x 3.5”, 2 x 2.5” drives HDD/SSDThree Fractal Design Silent Series R2 fans included with the case and space for an additional 7 fans.Excellent water cooling support with space for up to 4 radiators simultaneously.All intakes feature removable dust filters providing a dust-free interior.Featuring a window side panel to show off your set up in style.Additional space in the front to mount a slim optical bay drive and 2 x 2.5” drives.Fan controller included.Five expansion slots that allows for multiple GPU setups.SpecificationsMicro ATX and Mini ITX motherboard compatibility8 - 3.5” HDD positions2 - 2.5” dedicated SSD unit positions2 - Extra positions for either 3,5” or 2,5” drives5 expansion slots10 - Fan positions (3 x 120mm Silent Series R2 fans included)Filtered fan slots in front, top and bottomCPU coolers up to 160 mm in heightPSU compatibility: ATX PSUs up to 260 mm deepGraphics card compatibility: Graphics cards up to 320mm in length. Graphics cards up to 290 mm in length may be installed if a fan is installed in the lower position in the front.Velcro strap for easy cable managementClear Window side panel includedColors available: BlackCase dimensions (WxHxD): 344 x 307 x 389 mmNet weight: 6 kgPackage dimensions (WxHxD): 370 x 468 x 412 mmPackage weight: 7.7kgCooling systemFront: 4 – 120mm fans (included is one hydraulic bearing 120mm Silent Series R2 fan, 1000 RPM speed)Rear: 1 - 120/140mm fan (included is a hydraulic bearing 120mm Silent Series R2 fan, 1000 RPM speed)Rear: 1 - 120mm fan slots (included is 1 hydraulic bearing 120mm Silent Series R2 fan, 1000 RPM speed)Top: 4 - 120x140mm fans (not included)Fan controller: 1 - Integrated fan controller for up to 3 fans (included) Water cooling compatibilityFront (right chamber) - 240 mm radiator configurations up to 60 mm thick (with fans) and 278 mm tall are allowed.Front (left chamber) - 240 mm radiator configurations up to 60 mm thick (with fans) and 278 mm tall are allowed. Using a radiator in this position prevents the use of a fan in the top position just next to it.Top (right chamber) - 240/280 mm radiators up to 130mm thick (with fans) may be fitted if the HDD drive bays are taken out or placed elsewhere. No limitation to thickness.Top (left chamber) - 240 mm radiator configurations up to 130 mm thick (with fans) will fit. Radiators in this position limits the height of memory modules to 48 mm tall.Maximum radiator configuration: 1x240mm,1x280mm and 2x120mm radiators simultaneously. Front interface2 - USB 3.0Audio in/outPower button with LED (blue)HDD activity LED (white)Package contentsNode 804 computer caseAccessory boxUser manualAdditional informationEAN/GTIN-13: 7350041082019UPC: 817301012010Product code: FD-CA-NODE-804-BL-WAvailable for System Integrators

Typ produktu: kostka przypadku
Czarny kolor
EAN: 7350041082019
Kod producenta: FD-CA-NODE-804-BL-W
Seria: Węzeł
Projekt: wieża midi
Współczynnik kształtu płyty głównej: µATX
Zestaw okienny: Tak
Wymiary wewnętrzne: maksymalnie 320 mm
: maksymalnie 160mm
: ATX
: maksymalnie 260mm
Zatoki na dyski: 1 sztuka
: 8 sztuk
: 2 kawałki
Sloty: 5 sztuk
Przednie porty: 2x audio, 2x USB-A 3.2 Gen 1 (5 Gb/s)
: Oznaczenie USB 3.2 Gen 1 odpowiada wcześniejszemu oznaczeniu USB 3.1 Gen 1 / USB 3.0.
Przód: dostępny jeden wentylator 120 mm, możliwość zainstalowania trzech dodatkowych wentylatorów 120 mm
Tył: dostępny jeden wentylator 120 mm, można zainstalować kolejny wentylator 120 mm
Uwagi: na górze można zainstalować cztery wentylatory 140mm lub 120mm, zintegrowany kontroler wentylatora dla trzech wentylatorów; Filtry przeciwkurzowe z przodu, na górze i na dole obudowy
Możliwe chłodzenie wodą: Tak
: Obsługuj grzejniki 240/280mm na górze, obsługuj grzejniki 240mm z przodu
Wymiary: szerokość: 344mm x wysokość: 307mm x głębokość: 389mm
Waga: 6 kg

Fractal Design NODE 804. Model: PC, Obsługiwany typ płyty głównej: Micro-ATX, Mini-ATX, kolor: Czarny. Zainstalowane wentylatory przednie: 1x 120 mm, Obsługiwana średnica wentylatorów przednich: 120 mm, Zainstalowane wentylatory tylne: 2x 120 mm. Obsługuje rozmiary napędu dysku twardego: 2.5,3.5". Diody LED: HDD, Power. Szerokość produktu: 34,4 cm, Długość urządzenia: 38,9 cm, Wysokość urządzenia: 30,7 cm
