Intel Xeon E5-2623v4 10M Cache 2.60GHz

Code Name Broadwell Essentials Vertical Segment Server Processor Number E5-2623V4 Lithography 14 nm Performance # of Cores 4 # of Threads 8 Processor Base Frequency 2.60 GHz Max Turbo Frequency 3.20 GHz Cache 10 MB SmartCache Bus Speed 8 GT/s QPI # of QPI Links 2 TDP 85 W VID Voltage Range 0 Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 1.54 TB Memory Types DDR4 1600/1866/2133 Max # of Memory Channels 4 Max Memory Bandwidth 68.3 GB/s Physical Address Extensions 46-bit ECC Memory Supported ‡ Yes Expansion Options Scalability 2S PCI Express Revision 3.0 PCI Express Configurations ‡ x4, x8, x16 Max # of PCI Express Lanes 40 Package Specifications Sockets Supported FCLGA2011-3 Max CPU Configuration 2 T_CASE 73°C Package Size 45mm x 52.5mm Low Halogen Options Available See MDDS Advanced Technologies Intel® Turbo Boost Technology 2.0 Intel® vPro™ Platform Eligibility ‡ Yes Intel® Hyper-Threading Technology ‡ Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes Intel® TSX-NI Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Intel® Demand Based Switching Yes Thermal Monitoring Technologies Yes Intel® Flex Memory Access No Intel® Identity Protection Technology ‡ No Security & Reliability Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes

Intel E5-2623V4. Typ procesora: Intel Xeon E5 v4, Taktowanie procesora: 2.60 2600, Litografia procesora: 14 nm. Przepustowość pamięci obsługiwana przez procesor ( max ): 68,3 GB/s. Wersja gniazd typu Slot (PCI Express): 3.0, Instrukcje obsługiwania: AVX 2.0, Termiczny układ zasilania (TDP): 85 W. Intel Turbo Boost Technology: 2.0 Y. Maksymalna pamięć wewnętrzna: 1572864 MB
