hewlett packard enterprise HPE Aruba 4100i Switch 12G 8 Port Class 4 PoE and 4 Port Class 6 PoE 2 SFP+ Layer 2 Web GUI CLI NetEdit REST APIs

Aruba 4100i 12-port 1GbE (8-port Class 4 POE and 4-port Class 6 POE) 2-port SFP+ DIN Mount SwitchAruba 4100i 12-port 1GbE (8-port Class 4 POE and 4-port Class 6 POE) 2-port SFP+ DIN Mount Switch (JL817A)Description4x ports 100M/1G BaseT Class 6 PoE ports supporting up to 60W per port8x ports 100M/1G BaseT Class 4 PoE ports supporting up to 30W per port2x 1/10G SFP portsSupports PoE Standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W)1x USB-C Console Port1x RJ Console1x USB Type A Host port1x Alarm socket2x DC power socketPower SuppliesField replaceable Industrial DIN Rail Power SuppliesSupported PSUs: JL819A, JL820A and JL821ASupported 2 PSU with redundancy, non sharingSee external PSU specification table for available PoE powerFansFanlessPhysical CharacteristicsDimensions(H) 160 mm x(W) 113 mm x(D) 162.9 mm (173.5 mm w/DIN Rail Bracket)[6.3qqq1qqq1 x 4.4qqq1qqq1 x 6.4qqq1qqq1(6.8qqq1qqq1 w/DIN Rail Bracket)]Weight3.84 kg (8.46 lbs)Mounting And EnclosureCable management kit included. 2-post rack mounting kit included.4-post rack mounting kit available separatelyAdditional SpecificationsCPUDual Core ARM Cortex A9 @ 1016 MhzMemory And Flash4 GB DDR332 GB eMMCPacket Buffer12.38MB (4.5MB Ingress/7.875MB Egress)PerformanceModel Switching Capacityup to 64 GbpsModel Throughput Capacityup to 46 MppsAverage Latency (LIFO-64-bytes packets)1 Gbps: 2.390µSec , 10 Gbps: 2.038µSecSwitched Virtual Interfaces (dual stack)1G: 5.32 µSec10G: 1.48 µSec25G: 2.78 µSec40G: 1.31 µSec100G: 1.42 µSecIPv4 host table (ARP)756IPv6 host table (ND)576IPv4 unicast routes576IPv6 unicast routes576MAC Table Size8192IGMP Groups512MLD groups512IPv4/IPv6/MAC ACL entries (ingress)256 / 128 / 256EnvironmentOperating temperature-40°C to 60°C, 0m/s (-40°F to 140°F, 0 LFM)-40°C to 70°C, 0.2m/s (-40°F to 158°F, 40 LFM)-34°C to 75°C, 1m/s (-29.2°F to 167°F, 200 LFM)Non-Operating Storage relative humidity5% to 95%, non-condensingMax Operating Altitudeup to 4.2 km (13800 ft) MaxMax non-operating Altitude4.6 km (15000 ft) MaxElectrical CharacteristicsFrequencyN/AAC voltageRefer to the PSU specification tableDC Input Voltage54V (switch input voltage, provided by JL819A,JL820A, JL821A)CurrentJL820A- max 8A (360W PoE)JL819A, JL821A- max 4.4A (180W PoE)Maximum heat dissipation BTU/hrWith JL819A PSU:89 BTU/hr at 230V - Room temperature (25°C)With JL820A PSU:95 BTU/hr at 230V - Room temperature (25°C)With JL821A PSU:94 BTU/hr at 48V - Room temperature (25°C)Power Consumption(JL819A, JL820A- 230VAC)(JL821A- 48VDC)With JL819A PSU:Idle: 22W100% Traffic Rate: 26W100% Traffic Rate (w/ heater): 55W With JL820A PSU:Idle: 24W100% Traffic Rate: 28W100% Traffic Rate (w/ heater): 57W With JL821A PSU:Idle: 22W100% Traffic Rate: 27W100% Traffic Rate (w/ heater): 56W *Heater will only turn on at extreme lowtemperature conditionSafetyEurope:EN 60950-1:2006 + A11:2009 + A1:2010 +A12:2011 + A2:2013EN 62368-1, Ed.2:2014 North America:UL 62368-1, 2nd EditionCAN/CSA C22.2 No. 62368-1-14 Worldwide:IEC 60950-1:2005 Ed.2 + Am 1:2009 + A2:2013IEC 62368-1:2014EN/IEC 60825-1:2014 Class 1UL/IEC 61010-2-201GB 4943.1:2011CNS 14336-1K 60950-1EMCEurope:EN 55011:2010/CISPR 11, Class AEN 55032:2015/CISPR 32, Class AEN 55035:2017/CISPR 35EN 61000-3-2:2014, Class AEN 61000-3-3:2013 US:FCC CFR 47 Part 15: 2018 Class A Canada:ICES-003 Class A Japan:VCCI Class A Taiwan (BSMI)CNS 13438 Class A KoreaKN 35:2015 KoreaKN 32 Class A Aus/NZAS/NZS CISPR 32 Class A Worldwide:VCCI Class ACISPR 11 Class ACISPR 22 Class ALasersEN 60825-1:2007 / IEC 60825-1:2007 Class 1Class 1 Laser Products / Laser Klasse 1(Applicable for accessories - Optical Transceivers onlyIndustry Specific ComplianceIndustrialEN 61000-6-2 Industrial ImmunityEN 61000-6-4 Industrial EmissionsEN 61000-6-1 Light Industrial ImmunityPower SubstationIEEE 1613 Electric Power StationsCommunications NetworkingEN/IEC 61850-3 Electric SubstationsCommunications NetworkingRailway ApplicationEN 50121-3-2 Railway - Apparatus for Rolling StockEN 50121-4 Railway - Signaling and Telecommunications ApparatusEN 50155/IEC 60571 - Railway applications, Rolling stock, Electronic equipmentTraffic Control SystemNEMA TS 2-2016Protection StandardEN 60529 IP30ImmunityGenericEN 55035, CISPR 35, KN35ENEN 55035, CISPR 35ESDEN 61000-4-2 (air - 15kV, contact - 8kV)RadiatedEN 61000-4-3 (10V/m UTP, 20V/m STP)EFT/BurstEN 61000-4-44kV (1kV UTP, 4kV STP) using:JL819A, JL820A with SPD2-300-2P0-R surge protectorJL821A with SPD2-150-2P0-R surge protector needed.Without surge protector and STP:JL819A or JL820A PSU: 2kVJL821A PSU: 1kVSurgeEN 61000-4-52kV/4kV(UTP) using:JL819A, JL820A with SPD2-300-2P0-R surge protectorJL821A with SPD2-150-2P0-R surge protectorWithout surge protector:JL819A or JL820A PSU: 1kV/2kVJL821A PSU: N/AConductedEN 61000-4-6 (3Vrms UTP, 10Vrms STP)Power Frequency Magnetic FieldEN 61000-4-8 (100A/m 1min,1000A/m 1sec)Damped Oscillatory Magnetic FieldEN 61000-4-10 (100A/m)Conducted CM DisturbancesEN 61000-4-16 (30V, Cont/300V, 1 sec)Ripple Immunity DC PowerEN 61000-4-17 (10%)Damped Oscillatory WaveEN 61000-4-18 (2.5kV, 1MHz)Voltage Dips and interruptionsEN 61000-4-29; EN 61000-4-11 (Level 3)HarmonicsEN 61000-3-2, IEC 61000-3-2FlickerEN 61000-3-3, IEC 61000-3-3DynamicsVibrationIEC 60068-2-6 & 64 (operation & nonoperation)ShockIEC 60068-2-27 (Operational Shock, 30G, 18ms, Half-Sine)IEC 60068-2-27 (Non-operational Shock, 50G, 11ms, Trapezoidal)IEC 60068-2-31 (Non-operational Free Fall, 100mm)IEC 60068-2-31 (Non-operational Topple)Railway ApplicationCompliance to EN 50155 (mounting) & IEC 61373Mounting and EnclosureMounts to JL822A (3U DIN-to-Rack Bracket, puchased separately) which allows the switch to be mounted in an EIA/TIA standard 19qqq1qqq1 telco rack.Switch can be directly installed on a DIN rail mounted to a suitable surface to withstand the weight of the switch and power supplies.DIN rail mounting (included).Can be mounted in 90-degree manner to present the cables exiting the side of the switch - see installation guide for details.WirePower InputAWG 14 up to 2mAlarm connectorAWG 18-16PoE BudgetUser configurable PoE budget - If 2 external power supply units are used concurrently, please set according to PSU with lower PoE capacity. JL819ABelow ambient 50°C: 180WAt ambient 60°C: 140WAt ambient 70°C: 80W JL820ABelow ambient 50°C: 360WAt ambient 60°C: 320WAt ambient 70°C: 200W JL821AWith PSU input = 48V-55V DCBelow ambient 50°C: 180WAt ambient 60°C and 70°C: 150W With PSU input = 24V DCBelow ambient 70°C: 150W With PSU input = 12V DCBelow ambient 60°C: 60WAt ambient 70°C: 50W Does not support PSU Power Sharing. Refer to Installation & Getting Started Guide for the PoE budget setup.

HPE Aruba Networking CX 4100i 12p 1GbE 8p Class4 PoE and 4p Class6 PoE 2p SFP+ DIN Mount Switch. Typ przełącznika: Zarządzany, Warstwa przełącznika: L2. Podstawowe przełączania Ethernet RJ-45 porty typ: Gigabit Ethernet (10/100/1000), Podstawowe przełączanie RJ-45 Liczba portów Ethernet: 12, Port konsoli: RJ-45/USB Type-C. Wielkość tabeli adresów: 8192 wejścia, Przepustowość rutowania/przełączania: 128 Gbit/s. Standardy komunikacyjne: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Napięcie wejściowe DC: 12 - 48 V. Obsługa PoE. Możliwości montowania w stelażu, Układ: 4U
