CHERRY G84-4700 KEYPAD
Whether for numerical inputs, controls or for frequent number entry - the programmable keyboard is the ideal accessory for notebooks. All keys can be user-defined with up to 24 characters per key.
Individual keys with Gold Crosspoint contacts (ML technology)
Designed for continuous usage - over 20 mill. confirmations per key
Numeric block with 4 additional, individually inscribable function keys
High level of reliability and unique precision confirmation feeling
Programming of alternative key codes e.g. [.], [,],[00], [000]
Suitable for left and right-handed use
Additional programming of software macros via the high-performance configuration software 'Cherry Tools'
Can be used with the standard drivers of the operating system
TECHNICAL SPECIFICATIONS
Cable Length
approx. 1.75 m
Storage Temperature
-25°C to 65°C
Operating Temperature
0°C to 50°C
Current Consumption
typ. 5 mA
Connection sockets
PS/2 port (for connecting the keypad between the computer and standard keyboard)
Delivery Volume
- Keypad G84-4700- Operating instructions in hard copy
Dimensions (product)
approx. 90 x 132 x 36 mm
Packaging dimensions
approx. 140 x 185 x 45 mm
Reliability
- MTBF > 100,000 hours- MCBF > 10 bill. operations
Keyboard
Key technology
ML
Service life, standard key
> 20 million key operations
Operation characteristics
ML Pressure point (50cN)
Inscription technology
Laser
Inscription layout
Standard
Number of Keys
21
Number of additional keys
4
Number of inscribable keys
4
CHERRY G84-4700. Interfejs urządzenia: USB, Ilość klawiszy: 21, Przeznaczenie: Laptop/PC. Długość kabla: 1,75 m, Kolor produktu: Czarny. Waga produktu: 185 g
