JG936A Switch HPE FlexNetwork 5130 24G PoE+ 4SFP+ (370W) EI

I/O ports and slots 24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only4 SFP+ fixed 1000/10000 SFP+ ports Additional ports and slots 1 RJ-45 serial console port Physical characteristics Dimensions17.32(w) x 11.81(d) x 1.72(h) in (44 x 30 x 4.37 cm) (1U height)Weight17.64 lb (8 kg) Memory and processor 1 GB SDRAM, 128 MB flash; packet buffer size: 1.5 MB Mounting and enclosure Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included) Performance 1000 Mb Latency < 5 µs10 Gbps Latency < 1.5 µsThroughput 96 MppsRouting/Switching capacity 128 GbpsRouting table size 512 entries (IPv4), 256 entries (IPv6)MAC address table size 16384 entries Reliability MTBF (years) 48.3 Environment Operating temperature 32°F to 113°F (0°C to 45°C)Operating relative humidity 10% to 90%, noncondensingNonoperating/Storage temperature -40°F to 158°F (-40°C to 70°C)Nonoperating/Storage relative humidity 5% to 95%, noncondensingAcoustic Low-speed fan: 49.8 dB, High-speed fan: 52.9 dB; ISO 7779 Electrical characteristics Frequency 50/60 HzMaximum heat dissipation 102/1569 BTU/hr (107.61/1655.29 kJ/hr), for AC Power. For DC Power min heat dissipation is 85BTU/hr and max heat dissipation is 2559 BTU/hrAC voltage 100 - 240 VACCurrent 10 AMaximum power rating 460 WIdle power N/APoE power 370 W PoE+ Notes Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HP RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.Max current rating for DC power is 25A. AC Input power is 30W typical, and 460W max(including 370W PoE+ consumption. DC Input voltage range is -54 to -57VDC. Total DC input power is 25W Typical and 790W with 740W PoE+ Power consumption. DC Input voltage range is -54VDC to -57VDC. DC Input Source is the HP RPS1600.SafetyUL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; ROHS Compliance Emissions EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A; EN 61000-4-11:2004; ANSI C63.4-2009; EN 61000-3-3:2008; VCCI V-4/2012.04; EN 6100-3-2:2006+A1:2009 + A2:2009; EN 61000-3-2:2006+A1:2009+A2:2009 ; EN 61000-4-3:2006; EN 61000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009; AS/NZS CISPR 22:2009 Class A; CISPR 22:2008 Class A; EN 55022:2010 Class A; EN 61000-4-29: 2000; CISPR 24:2010; EN 300 386 V1.6.1; VCCI V-3/2013.04 Class A Immunity Generic EN 55024ESD EN300 386 Management IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager Services Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.
